Lýsing 360°, 6 dB LTE 4×4 MIMO loftnet. Þetta hentar vel þar sem að er lélegt netsamband. Tengist beint í router. Next-Generation 4×4 MIMO Ultra-Wideband Antenna for Superior 5G & LTE Performance The XPOL-1-5G is POYNTING’s third-generation “V3” version of its popular Cross Polarised (XPOL) cellular band antenna, available in 2×2 and 4×4 MIMO configurations. This version has been fully redesigned with a modern enclosure and enhanced antenna design, now supporting an ultra-wide frequency range from 410 to 6000 MHz. It is compatible with a wide range of cellular networks and is future-ready for 5G applications up to 6 GHz. Ultra-Wideband Frequency Range: Supports 410 – 6000 MHz for compatibility with legacy and future 5G technologies. Powerful 4×4 MIMO Performance: Features four cross-polarised cellular antennas in one enclosure, enabling improved data throughput and link reliability. High Peak Gain of 7 dBi: Offers more than double the gain of the previous V2 version, delivering extended coverage and stronger signals for Fixed Wireless Access (FWA). Omni-Directional Radiation Patterns: Carefully engineered for consistent coverage across urban, suburban, and commercial environments. Durable & Weather-Resistant Enclosure: IP65-rated design protects against dust, water, and vandalism, making it ideal for harsh outdoor use. The XPOL-1-5G is a next-generation, high-performance antenna solution designed to maximise cellular connectivity across diverse deployment scenarios, ensuring excellent performance for current and future networks. Ideal Applications Outdoor antenna for Fixed Wireless Access (FWA) Homes and small offices in both urban and suburban environments Small to medium-sized businesses across various commercial and industrial sectors such as retail outlets, petrol stations, guesthouses, banks, etc. Temporary offices on construction sites Serve as a reliable backup connectivity option for locations that use fibre or Starlink as their primary internet connection Meira um netið hér Technical Specifications for XPOL-1-5G Plus (4×4 MIMO) Industry (Application) Commercial & Industrial Antennas, Farming & Agricultural Antennas, Urban & Rural Cellular Antennas Technology Cellular (LTE/2G/3G/4G/5G) Cellular Freq. Range 410 – 6000 MHz Frequency Band 410-450MHz, 433MHz, 450-470MHz, 617-698MHz, 698-803MHz, 791-894MHz, 868-915MHz, 880-960MHz, 1427-1517MHz, 1700-1900MHz, 1900-2200MHz, 2300-2400MHz, 2400-2500MHz, 2500-2700MHz, 3300-3800MHz, 3800-4200MHz, 4400-6000MHz 5G Bands n50, n91, n92, n93, n94, n1, n2, n3, n5, n7, n8, n12, n13, n14, n18, n20, n25, n26, n28, n29, n30, n31, n34, n38, n39, n40, n41, n46, n48, n51, n53, n65, n66, n67, n71, n72, n74, n75, n76, n77, n78, n79, n80, n81, n82, n83, n84, n85, n86, n89, n90, n95, n97, n100, n101, n106 LTE/4G Bands B50, B51, B1, B2, B3, B4, B5, B7, B8, B9, B10, B12, B13, B14, B17, B18, B19, B20, B25, B26, B27, B28, B29, B30, B33, B34, B35, B36, B37, B38, B39, B40, B41, B42, B43, B46, B47, B48, B53, B65, B66, B67, B68, B69, B71, B72, B73, B74, B85, B87, B88, B103, B106 Wi-Fi Standard Wi-Fi 3 (802.11g), Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) Gain 7dBi Directionality Omni-Directional Mounting Type Pole Mount, Wall Mount, Window Mount Connectors SMA MIMO 4×4 Polarisation X-Polarised Environmental IP65 LTE Ports 4
